Toshiba e-STUDIO4500c Service Manual

COMMON REMOVAL PROCEDURES August, 2006
3-14
IMPORTANT
• T
HE OPC DRUM IS EXPOSED ON THE BOTTOM OF THE PCU.
• NEVER PLACE YOUR HAND UNDER THE PCU.
• N
EVER PLACE THE PCU ON ANY SURFACE OTHER THAN THE PCU STAND.
14. Set the PCU [A] on the PCU stand [B].
NOTE: In the diagram, F is the front, and R is the rear.
F
R
B132R214.WMF
[A]
[B]
