August, 2006 FUSING UNIT
3-95
Remove:
[E]: Cleaning felt roller Assy
[F]: Cleaning felt roller
[G]: Bracket
[H]: Springs
[I]: Bushings
[E]
[F]
[G]
[H]
[H]
[I]
[I]
