ARDF August, 2006
3-166
Remove:
[A]: Bracket ( x1)
[B]: Original registration sensor
( x1)
[C]: Bracket ( x1)
[D]: Original exit sensor ( x1)
B132R113.WMF
B132R115.WMF
[A]
[B]
[C]
[D]
