SPECIAL PROCEDURES April, 2007
4-12
Color Skew Error Correction
1. Start SP 2109 002 and select pattern 1 (1-dot line), then push the “OK” button.
2. Push the “Copy Window” button. Then select A3/DLT paper, and push the
“Start” button to print the pattern.
NOTE: Make sure that “Full Color Mode” is selected before you push the Start
button.
In the example above, the dotted lines are magenta, cyan, or yellow, and the
solid lines are black.
3. Correct the skew. See the following table for how to do this
Right SP Action
To Next Page
