Toshiba e-STUDIO4500c Service Manual

April, 2007 SERVICE PROGRAM TABLES
5-21
Abbreviations for e-STUDIO4500c/5500c SP Service Tables
The SP titles are abbreviated so they can be used in smaller the 2-line displays of future printer
models. Refer to this list if you do not understand the meaning of an abbreviation.
Code Meaning Code Meaning Code Meaning
1/3S
One-third Speed
HS
Half Speed
Recov
Recovery
1C
One Color
Htg
Htg
Reg
Registration
1Op
1 Operation (execution
cycle)
Htg Roll
Heating Roller
Reps
Repetitions
1-S
1-Side (Simplex)
I/O
Input/Output
Rev
Reverse
2-S
2-Side (Duplex)
Init
Initial power ON
Roll
Roller
Abs
Absolute
Int
Interval
Rot
Rotation
Adj
Adjustment
IntCnt
Interval Count
s
seconds
Agi
Agitation
Inv
Inverter
S
Sideways (LEF)
Amt
Amount
ITR
Image Transfer
SApli
Scanner Application
B/W
Black-and-White (2-Color)
JG
Junction Gate
Sep
Separation
BotPlt
Bottom Plate (Tray)
K
Black, BK
Shts
Sheets
C
Cyan
L
Lengthways (SEF)
Sn
Sensor
Calib
Calibration
LEdge
Leading Edge
Sp1
Special Paper 1
Chg
Change
LL
Lowest (Low Low)
SS
Saddle-Stitch
Chk
Check
Lvl
Level
Std
Standard
Chrg
Charge
M
Motor
Stp
Staple
Cir.
Circulation
M
Magenta
StrTemp
Start Temperature
Cnt
Count
Meas
Measurement
Sub
Sub Hopper
Coeff
Coefficient
Mem
Memory
SWT
Switch Timing
Col
Color
MH
Medium High
Syn
Synchronization
Cont
Continuous Operation
ML
Medium Low
T1
Tray 1
Cor
Correction
MM
Medium (Medium Medium)
T2
Tray 2
Ctrl
Control
Norm
Normal Paper
T3
Tray 3
Den
Density
NS
Normal Speed
T4
Tray 4
Dev
Development
Opt.
Optical
Tan
Tandem
Devr
Developer
Patt
Pattern
TC
Toner Control
Disp
Display
PE
Paper End
TE
Toner End
Dupx
Duplex
Pgs
Pages
TE Sn
Toner End Sensor
EMargin
Erase Margin
Pht
TEdge
Trailing Edge
EngSave
Energy Save
PM
Pulse Modulation
Temp
Temperature
Ent
Entrance
PolyM
Polygon Motor
Temp
Chg
Temperature
Change
Env
Environment
Pos
Position
Thk
Thick (Paper)
Err
Error
Poten
Potential
Thresh
Threshold
Exe
Execute
PPr
Photo Paper
Tmg
Timing
FC
Full Color
Press
Pressure
TNE
Toner Near End
Fin1
SR970 (B701) and
SR4000 (B700)
Prior
Priority
Tnr
Toner
Fin2
SR842 (B706)
Prmr
Parameter
Tnr M
Toner Motor
Fin3
- (Japan only)
ProCon
Process Control
Tra
Trace (thin) Paper
Fwd
Forward
Pt
Point
TxtOCR
Text (OCR)
Gray
Grayscale
PT
Paper Transfer
TxtPrt
Text (Print)
Haf
Half Speed
PTR
Paper Transfer Roller
Usd Tnr
Used (Waste)
Toners
Height
Hgt
Ptype
Paper Type
Vert
Vertical
HH
Highest (High High)
Pwr
Power
Y
Yellow
