Toshiba e-STUDIO4500c Service Manual

April, 2007 SERVICE PROGRAM TABLES
5-31
1202
Set Fusing Temp Set Fusing Temperature (for shift to low power mode)
This SP sets the time interval for the machine to remain idle to trigger lower power
mode 1.
Set Fusing Temp
001
EngSave Time 1 [0~60/1 min.]
002
EngSave Time 2 [0~90/5 min.]
003
EngSave Time 3 [0~24/0.5 hour]
Heating Roller
004
Energy Save 1 [-200~0/1 deg.]
005
Energy Save 2 [-200~0/1 deg.]
006
Energy Save 3 [-200~0/1 deg.]
Pressure Roller
007
Energy Save 1 [-200~0/1 deg.]
008
Energy Save 2 [-200~0/1 deg.]
009
Energy Save 3 [-200~0/1 deg.]
Hot Roller
010
Energy Save 1 [-200~0/1 deg.]
011
Energy Save 2 [-200~0/1 deg.]
012
Energy Save 3 [-200~0/1 deg.]
1203
Fusing:I/O Fusing Input/Output
This SP adjusts the operation of the fusing exit sensor.
001 FuseExitSn:On/Off Display indicates whether the fusing exit sensor is ON or
OFF.
0: OFF 1:ON
002 FuseExitSn Timing Displays the time interval from when the registration motor
goes OFF to when it restarts.
[0~5000/1 msec.]
003 FuseExitSn ON Display indicates whether the fusing paper remains sensor is
ON or OFF.
[0~5000/1 msec.]
004 FuseExitSn Disp Dsiplays whether the paper remains sensor is ON or OFF
from when the registration motor goes OFF until it restarts.
0: OFF 1:ON
005 FuseExit M ON Switches forced rotation of the fusing/exit motor ON/OFF.
0: OFF 1:ON
1901
CPM Down:Thk CPM Down Mode: Thick Paper
This SP adjusts the CPM down time for thick paper and tab sheets.
001 CPM Down:Thk Special CPM Down Setting: Thick Paper
[0~4/1] (This function in not used in this model.)
002 CPM Down:Tab Special CPM Down Setting: Index Tabs
[0~4/1] (This function in not used in this model.)
