Book Fold Adj Adjusts the booklet folding position
These SPs adjust the position for booklet stapling with the 2000/3000-Sheet Finisher
B700. The initial setting is at "0" and can be adjusted in increments of 0.2 mm
001 A3 SEF:Sub Scan [-3 to +3/0.2 mm]
002 B4 SEF:Sub Scan
003 A4 SEF:Sub Scan
004 B5 SEF:Sub Scan
005 DLT SEF:Sub Scan
006 LG SEF:Sub Scan
007 LT SEF:Sub Scan
008 12"x18":Sub Scan
009 Custom:Sub Scan
6900
ADF Bottom Lift ADF Bottom Lift Plate
This SP setting determines whether the bottom plate lift motor of the of the ARDF
switches on when the original is set in the ARDF original tray, or when the [Start] key
is pressed. The ARDF bottom plate lift motor raises the bottom plate that pushes up
the original tray and raises it to the optimum feed position.
[0~1/1]
0: Bottom plate lifts immediately after originals are set (Default)
1: Bottom plate does not lift until [Start] key is pressed.
