SERVICE PROGRAM TABLES August, 2006
5-146
7504
Paper Jam Loc Paper Jam Location – All Finishers
Displays the list of possible locations where a jam could have occurred. Press the
appropriate key to display the jam count for that location. These jams are caused by
the failure of a sensor to activate.
On Operation Panel Actual Component Name
230
Fin:No Ex Response Finisher:No Exit Response
7505
Original Jam Det Original Jam Detection – ARDF
Displays the list of possible locations where a jam could have occurred. Press the
appropriate key to display the jam count for that location. These jams are caused by
the failure of a sensor to activate.
On Operation Panel Actual Component Name
001
At Power On At Power On
003
Separation Sn:Late Separation Sensor:Late
004
Skew Cor Sn:Late Skew Correction Sensor:Late
005
Interval Sn:Late Interval Sensor:Late
006
Reg Sn:Late Registration Sensor:Late
007
Exit Sn:Late Exit Sensor:Late
008
Inv Switch Sn:Late Inverter Switchback Sensor:Late
009
Low Inv Sn:Late Lower Inverter Sensor:Late
053
Separation Sn:Lag SeparationsSensor:Lag
054
Skew Cor Sn:Lag Skew Correction Sensor:Lag
055
Interval Sn:Lag Interval Sensor:Lag
056
Reg Sn:Lag Registration Sensor:Lag
057
Exit Sn:Lag Exit Sensor:Lag
058
Inv Switch Sn:Lag Inverter Switchback Sensor:Lag
059
Low Inv Sn:Lag Lower Inverter Sensor:Lag
