August, 2006 COPIER INPUT/OUTPUT CHECK
5-201
5804 Output Chk Output Check
113 Feed Mtr 1:Rev/Nor M3 155
Dup Inv M:Fwd/Hi M22
114 Feed Mtr 1:Rev/Haf M3 156
Dup Inv M:Fwd/Haf M22
115 Feed Mtr 2:Fwd/Nor M2 157
DupInvM:Fwd/TS M22
116 Feed Mtr 2:Fwd/Hi M2 158
DupTrans M:Fwd/Nor M21
117 Feed Mtr 2:Fwd/Haf M2 159
DupTrans M:Fwd/Hi M21
118 Feed Mtr 2:Rev/Nor M2 160
DupTrans M:Fwd/Haf M21
119 Feed Mtr 2:Rev/Haf M2 161
Dup JG SOL SOL11
120 Feed Mtr 3:Fwd/Nor M5 162
Inv Pos SOL SOL12
121 Feed Mtr 3:Fwd/Hi M5 163
Dup Trans CL ---
122 Feed Mtr 3:Fwd/Haf M5 164
Dup Jog M:HP Sn S45
123 Feed Mtr 3:Rev/Nor M5 169
Drum Mtr:K M45
124 Feed Mtr 3:Rev/Haf M5 170
Drum Mtr:K:Haf M45
125 Feed Mtr 4:Fwd/Nor M4 171
Drum Mtr:M M44
126 Feed Mtr 4:Fwd/Hi M4 172
Drum Mtr:M:Haf M44
127 Feed Mtr 4:Fwd/Haf M4 173
Drum Mtr:C M43
128 Feed Mtr 4:Rev/Nor M4 174
Drum Mtr:C:Haf M43
129 Feed Mtr 4:Rev/Haf M4 175
Drum Mtr:Y M42
130 Bypass Feed CL MC1 176
Drum Mtr:Y:Haf M42
131 Pick-up SOL:Tray 1 SOL5 177
PCU Mtr:K M37
132 Pick-up SOL:Tray 2 --- 178
PCU Mtr:K:Haf M37
133 Pick-up SOL:Tray 3 SOL1 179
PCU Mtr:M M36
134 Pick-up SOL:Tray 4 SOL3 180
PCU Mtr:M:Haf M36
135 Bypass Pick-up SOL
PCU Mtr:C M39
136 Rev SOL:Tray 1 SOL6 182
PCU Mtr:C:Haf M39
137 Rev SOL:Tray 2 --- 183
PCU Mtr:Y M38
138 Rev SOL:Tray 3 SOL2 184
PCU Mtr:Y:Haf M38
139 Rev SOL:Tray 4 SOL4 185
Image Transfer Motor M46
140 Tan Conn Rel SOL SOL9 186
Image Transfer Motor:Haf M46
141 Tan Lock SOL SOL10 187
PRT Motor M17
142 TanShift M:Fwd/Rev
PRT Motor:Haf M17
145 Relay Mtr:Fwd/Nor M18 189
Fusing/Exit M M16
146 Relay M:Fwd/Dup M18 190
Fusing/Exit M:Haf M16
147 Relay M:Fwd/Haf M18 191
Fusing/Exit M:1/3 M16
148 Relay M:Rev/Nor M18 192
ITB Lift M:Fwd M11
149 Relay M:Rev/Haf M18 193
ITB Lift M:Rev M11
150 Reg Mtr:Rev/Haf M23 194
Jam LED:Fusing LED2
151 Reg Mrt:Half Spd M23 195
Jam LED:Exit LED3
152 Guide Rel SOL SOL13 200
Scanner Fan M56
153 Exit JG SOL SOL14 202
Scanner Lamp L1
154 Dup Inv M:Fwd/Nor M22 203
Scanner Motor M1
NOTE: --- means "not used"
