August, 2006 SCANNER UNIT

6-35

Detailed

Descriptions

6.5.4 SCANNER UNIT FANS AND ANTI-CONDENSATION HEATER

[A]: Scanner cooling fan (front)

[B]: Scanner cooling fan (rear)

[C]: Scanner exhaust fan

Condensation on the mirrors can cause:

• Running, smearing and image borders

• Printing completely black or gray pages

Fans

• The scanner cooling fans (front, rear) pull cool air into the scanner unit.

• The scanner exhaust fan expels hot air from the scanner unit

B132D104.WMF

[A]

[C]

[B]
