Toshiba e-STUDIO4500c Service Manual

August, 2006 A3/11" X 17" PAPER SIZE TRAY (B331)
1-45
Installation
3. Open the front doors.
4. Pull out the tandem feed tray [A] fully.
5. Push the right tandem tray [B] into the machine.
6. Remove the left tandem tray [C] ( x 2 left,  x 3 right).
B331I707.WMF
B331I708.WMF
[A]
[B]
[C]
