Important: Support the fold unit with your hand to prevent it from falling.
CAUTION: The fold unit is heavy.
[A]: Fold unit ( x4, x2, x6)
If you have replaced the fold unit:
1. Read the DIP SW settings on the decal [B] attached to the back of the new fold
unit.
2. Check the DIP SW settings on the main board [C] of the finisher.
3. If these settings are different, change these settings to match settings printed
on the seal attached to the fold unit.
NOTE: Set DIP switches 1 to 4 (the switch set on the right). Do not touch the
other DIP switches.
