Paper direction
The operation of the proof tray and stapler junction gates direct the flow of the
paper once it enters the finisher:
Proof Junction Gate
Stapler Junction Gate Paper Feeds
Closed Closed Paper feeds straight through
Open
Closed Paper feeds to the proof tray
Closed
Open
Paper feds to the staple tray
Proof tray
Copies are sent to the proof tray (12) when neither sorting nor stapling are selected
for the job.
Upper tray
The upper tray (11) receives copies that are sorted and shifted and also receives
copies that have been corner stapled. Corner stapling is provided on both the B700
and the B701.
Pre-stack tray
The pre-stack tray (5) has a switchback mechanism to increase the productivity of
stapling. (2.5) Pre-stacking is done for corner stapling in the B700/B701 and for
booklet stapling in the B700.
Lower tray
The lower tray (7) receives copies that have been center folded and stapled
(booklet stapling). Booklet stapling is not provided on the B701.
