August 2006 LOWER TRAY (B700 ONLY)
B700-43
Peripherals
The tray full detection depends on the size of the paper and the number of sheets
in one stapled and folded booklet.
In the table below, the conditions ( Ready Full 1, Full 2 Full 3: See the
illustration on the previous page) refer to the states of the sensors described on the
previous page.
Condition Front Sensor Rear Sensor
Ready ON OFF
Full 1 ON ON
Full 2 OFF ON
Full 3 (or lower tray not installed)
OFF OFF
In the tables below:
• "Sht" denotes "sheets in a stack".
• "Cnt" denotes "Count" (see below for an explanation).
After a booklet is feed out, the fold roller motor stops the exit roller. The machine
then monitors the tray full sensors every 100 ms. The machine checks for a certain
condition, based on the size of the paper and the number of sheets in the booklet.
An example is shown below. Tell the operators that the number of sheets that the
lower tray can hold will vary greatly.
Lower Tray Full Condition Table
A3 (DLT)
1 Sht 2 Sht 3 Sht 4 Sht 5 Sht 6 Sht 7 Sth 8 Sht 9 Sht …
Full 1
3 Cnt
— — — — — — — — …
Full 2
4 Cnt 2 Cnt 2 Cnt 2 Cnt
…
A4 (LT)
1 Sht 2 Sht 3 Sht 4 Sht 5 Sht 6 Sht 7 Sth 8 Sht 9 Sht …
Full1
16 Cnt
— — —
…
Examples
After the copier makes a booklet with 1 sheet of A3/DLT paper, the machine
checks every 100 ms for the ‘Full 1’ condition. If the Full 1 condition occurs 3 times
(shaded block in the table above), the machine detects that the tray is full.
After the copier makes a booklet with 5 sheets of A4/LT paper, the machine checks
every 100 ms for the ‘Full 2’ condition. If the Full 2 condition occurs 20 times
(shaded block in the table above), the machine detects that the tray is full.
