At the beginning of the job, the jogger fence motor (M15) [A] switches on and
moves the jogger fences [B] to the standby position (7.5 mm from the sides of the
selected paper size).
When each sheet passes the pre-stack tray exit sensor (S2) and enters the
stapling tray:
• The jogger fence motor switches on and moves the jogger fences to within 5.5
mm of the sides of the selected paper size.
• The positioning roller solenoid (SOL3) switches on for the time prescribed for the
paper size. This pushes the positioning roller [C] onto the sheet and pushes it
down onto bottom fence. This aligns the edge of the stack.
Next, the jogger fence motor:
• Switches on again and moves the jogger fences to within 2.6 mm of the sides of
the stack to align the sides of the stack.
• Reverses and moves the fences to the standby position (7.5 mm away for the
sides) and waits for the next sheet.
• The jogger fence HP sensor [D] switches off the jogger motor at the end of the
job.
After the last sheet feeds:
• The stapling edge pressure plate solenoid [E] (SOL4) switches on and pushes
the pressure plate [F] onto the stack to press down the edge for stapling.
• The corner stapler staples the stack.
