Toshiba e-STUDIO4500c Service Manual

PUNCH UNIT B702 (FOR B700/B701) August 2006
B700-64
These SP codes adjust the punch hole alignment:
• SP6101 Adjusts the punch positions in the direction of paper feed.
• SP6102 Adjusts the punch position perpendicular to the direction of feed.
For more, see Section "5. Service Tables".
B700D360.WMF
SP6102 SP6101
