September 2006 OVERVIEW
B704-11
Peripherals
The table below lists the sensor output for each paper size.
S1 S2 S3 S4 S5 S6
A3 0 1 1 1 1 1
B4 1 1 0 1 1 1
A4 SEF 1 0 0 1 1 0
A4 LEF 0 1 1 0 0 0
B5 SEF 0 0 0 1 0 0
B5 LEF 1 1 0 0 0 0
A5 SEF 0 0 0 0 0 0
A5 LEF 1 0 0 0 0 0
11" x 17" 1 1 1 1 1 1
10" x 14" SEF 1 1 0 1 1 1
81/2" x 14" 1 0 0 1 1 1
81/2" x 13" 1 0 0 1 1 1
81/2" x 11" 1 0 0 1 0 0
11" x 81/2" 1 1 1 0 0 0
8" x 10" 1 0 0 1 0 0
51/2" x 81/2" 0 0 0 0 0 0
81/2" x 51/2" 1 0 0 0 0 0
71/2" x 101/2"
(US Exec.)
0 0 0 1 0 0
101/2" x 71/2"
(US Exec.)
1 1 1 0 0 0
8 K 1 1 1 1 1 1
16 K SEF 1 0 0 1 0 0
16 K LEF 1 1 1 0 0 0
The cover interposer tray detects all the paper sizes listed above. However, there
are some limitations on the display of the correct paper size.
North America Europe/Asia
B4 SEF 257 x 364 mm Displays 10”x14
*1
B5 SEF 182 x 257 Displays “US Exec.”
*1
A5 SEF 148 x 210 Displays “HLT SEF”
*1
A5 LEF 210 x 148 Displays “HLT LEF”
*1
DLT SEF 11" x 17" Displays “8K LEF”
*2
LG SEF 81/2" x 14" Displays “F4 SEF”
*2
LT SEF 81/2" x 11" Displays “16 K SEF”
*2
LT LEF 11" x 81/2" Displays “16 K LEF”
*2
*1
: Cannot be corrected.
*2
: B064 series: Can be corrected with SP5959 006 (Paper Size – Cover Sheet).
B140 series: Can be corrected with SP5158
