TX2560 M2 / RX2560 M2 Upgrade and Maintenance Manual
297
Expansion cards and backup units
Figure 205: Installing the expansion card - example PCI slot 1 (A)
Ê
Carefully insert the expansion card into the desired PCI slot and press down
firmly until it is fully seated in the slot.
I
For slot preferences, please refer to section "Basic information" on
page 290.
