Upgrade and Maintenance Manual TX2560 M2 / RX2560 M2
Converting a tower model to a rack model
Removing the accessible drive cage
Ê
Remove the front panel module as described in section "Removing the front
panel module" on page 437.
Ê
If applicable, remove all accessible drives as described in section
"Removing an accessible drive" on page 402.
Ê
If applicable, remove an HDD extension box as described in section "HDD
extension boxes" on page 237.
Figure 368: Detaching the accessible drive cage (A)
Ê
Remove the two screws (see circles) from the bottom side of the server.
Ê
Bring the server back to its horizontal position.
I
At least two people are needed to turn over a fully equipped server.
Remove HDDs and PSUs in order to facilitate the task.
