Command Manual - Routing Protocol
Quidway S3500 Series Ethernet Switches Chapter 1 Static Route Configuration Commands
Huawei Technologies Proprietary
1-15
Age: 37:42 Cost: 0/0
First, display statistics of the whole routing table and then output detailed information of
every route entry in turn. The meaning of route status is shown in Table 1-2, and the
statistics of routing table is shown in the following table.
Table 1-5 Description of information generated by the command display ip
routing-table verbose
Field Description
Holddown Number of held-down routes
Delete Number of deleted routes
Hidden Number of hidden routes
1.2 Static Route Configuration Commands
1.2.1 ip route-static
Syntax
ip route-static ip-address { mask | mask-length } { interface-name | gateway-address }
[ preference preference-value ] [ reject | blackhole ]
undo ip route-static ip-address { mask | mask-length } [ interface-name |
gateway-address ] [ preference preference-value ]
View
system view
Parameter
ip-address: Destination IP address in dotted decimal notation.
mask: Mask.
mask-length: Mask length. Since "1" s in the 32-bit mask are required to be consecutive,
the mask in dotted decimal format can be replaced by mask-length, which is the
number of the consecutive "1" s in the mask.
interface-name: Specify the interface of the route. The packets that are sent to a NULL
interface, a kind of virtual interface, will be discarded immediately. Thus can decrease
the system load.
gateway-address: Specify the next hop IP address of the route.
preference-value: Preference level of the route in the range from 1 to 255.
reject: Indicate an unreachable route.
blackhole: Indicate a blackhole route.
