Command Manual - QoS/ACL
Quidway S3500 Series Ethernet Switches Chapter 1 ACL Commands
Huawei Technologies Proprietary
1-13
z For S3526, S3526 FM, S3526 FS switches, parameter icmp-type is only supported
when user defines advance ACL. ICMP packet type and code (the parameter type
code in rule command) can’t be configured. Otherwise the system will prompt the
configuration is not available.
z The restrictions corresponding to each QoS function describe the ACL rule available
in configuring this function. Other ACL rules will not be used in implementing this
function in S3526. Otherwise, the system will return error prompts.
z Define the ACL rules to be used in it first before implementing a QoS function.
For related configurations, refer to command acl.
Example
# Add a rule to an advanced ACL.
[Quidway-acl-adv-3000] rule 1 permit tcp established source 1.1.1.1 0
destination 2.2.2.2 0
# Add a rule to a basic ACL.
[Quidway-acl-basic-2000] rule 1 permit source 1.1.1.1 0 fragment
# Add a rule to an L2 ACL.
[Quidway-acl-link-4000] rule 1 permit ingress 1 egress any
1.1.8 time-range
Syntax
time-range time-name { start-time to end-time days-of-the-week [ from start-time
start-date ] [ to end-time end-date ] | from start-time start-date [ to end-time end-date ] }
undo time-range time-name [ start-time to end-time days-of-the-week [ from
start-time start-date ] [ to end-time end-date ] | from start-time start-date [ to end-time
end-date ] ]
View
System view
Parameter
time-name: Name of a special time range to be referenced.
start-time: Start time of the special time range, format as hh:mm.
end-time: End time of the special time range, format as hh:mm.
days-of-the-week: Determines in which day(s) of a week in the special time range a
command takes effect. You can specify this parameter with any of the following values.
Numbers (ranging from 0 to 6);
