Item Specicaon
Projecon angles Angulaon: 45 degr
ees caudal to 45 degrees cranial
Rotaon: 120 degrees LAO to 120 degrees RAO
Isocenter to oor 106.5 cm (41.9 inch)
Focal spot to isocenter 76.5 cm (30.1 inch)
Focal spot to detector (source-to-image distance) 89.0 to 123.5 cm (35.0 to 48.6 inch)
Detector movement speed Toward the paent: 10 cm/s
Away from the paent: 20 cm/s
Throat depth 105 cm (41.3 inch)
Motorized stand rotaon 90 degrees le to 90 degrees right at 12 degrees/s
Rotaon scan From 120 degrees RAO (-rotaon) to 120 degrees LAO (+ro-
taon) at a speed of up to 55 degrees/s
C12 System
The X
-ray beam eld is always aligned with the image receptor area and the reference axis is always
perpendicular to the image receptor plane.
Item Specicaon
Rotaon speed 0 - 25 degrees/s (variable)
These speeds ar
e only valid when the stand is in its working
posion, otherwise the maximum speed is 8 degrees/s
Angulaon speed 0 - 25 degrees/s (variable)
These speeds are only valid when the stand is in its working
posion, otherwise the maximum speed is 8 degrees/s
Projecon angles with the C-arm posioned at the head
end of the table
Angulaon: 45 degrees caudal to 45 degrees cranial
Rotaon: 120 degrees LAO to 120 degrees RAO
Projecon angles with the C-arm posioned at the side of
the table
Angulaon: 120 degrees caudal to 120 degrees cranial
Rotaon: 45 degrees LAO to 45 degrees RAO
Isocenter to oor 106.5 cm (41.9 inch)
Focal spot to isocenter 76.5 cm (30.1 inch)
Focal spot to detector (source-to-image distance) 89.0 to 123.5 cm (35.0 to 48.6 inch)
Detector movement speed Toward the paent: 10 cm/s
Away from the paent: 20 cm/s
Throat depth 105 cm (41.3 inch)
Longitudinal movement (manual or motorized) 260 cm (102.4 inch)
With extended ceiling rail (opon): 410 cm (161.4 inch)
Motorized longitudinal movement speed (opon) 15 cm/s
Motorized stand rotaon 90 degrees le to 90 degrees right at 12 degrees/s
Rotaon scan Propeller movement: From 120 degrees RAO (-rotaon) to
120 degrees LAO (+rotaon) at a speed of up to 55
degrees/s
Roll movement: From 45 degrees LAO to 45 degrees RAO at
a speed of up to 30 degrees/s
Minimum ceiling height 270 cm (106 inch)
F15 System
The X
-ray beam eld is always aligned with the image receptor area and the reference axis is always
perpendicular to the image receptor plane.
Item Specicaon
Rotaon speed 0 - 25 degrees/s (variable)
These speeds ar
e only valid when the stand is in its working
posion, otherwise the maximum speed is 8 degrees/s
