Label item Content
— Voltage values, current r
ang, operat-
ing frequency and fuse rang
For more in
formaon, see the following secons:
• Wall Connecon Box (page 287)
• Installaon and Equipment Connecons (page 344)
Wall Connecon Box WCB-x Variant
Labels for the WCB-x variant of the wall connecon box can be found on the front and side of the box.
Figure 169 Idenc
aon label, WCB-x variant
The idencaon label contains the following informaon:
Label item Le side Right side
Type/Model WCB-x (PRODRIVE) Fuse r
ang
PN Part number (PN) Input X1: Voltage values and operang fre-
quency
SN Serial number (SN) Output X2: Voltage values and operang fre-
quency
12NC 12 digit numeric code Output X4: Voltage and current values
Barcode Scan idencaon code —
For more in
formaon, see the following secons:
• Wall Connecon Box (page 287)
• Installaon and Equipment Connecons (page 344)
Cabinets
The labels for the X-ray control can be found on the top of the M-cabinet.
Technical In
formaon Equipment Labels
