Philips Azurion - Page 337

To Next Page

To Previous Page

Figure 170 P

osion of labels on the X-ray control unit

The labels for the X-ray generator can be found on the top of the Generator cabinet.

Figure 171 P

osion of labels on the X-ray generator

XperGuide Laser Tool Label

The label for the XperGuide laser tool provides basic informaon about the model number, part

number, serial number and manufacturer.

Figure 172 XperGuide laser tool label

Technical In

formaon Equipment Labels

Azurion Release 1.2 Ins

trucons for Use 337 Philips Healthcare 4522 203 52421
