Status Area in the Ex
aminaon Room (Monoplane System)
13
16
17
Figure 186 St
atus area in the examinaon room live X-ray window
Legend Descripon
1
System status The system is ready for exposure.
System status The system is not ready for exposure.
2
X-ray status X-ray is on.
X-ray status X-ray is disabled.
3
Tube load The tube is overheated.
4
Fluoroscopy Fluoroscopy sengs ar
e displayed.
Exposure Exposure sengs ar
e displayed.
- kV
X-ray generator sengs- mA
- ms
5
- LAO C-arm rotaon angle.
- CRAN C-arm angulaon angle.
6 - SID The actual or target source-to-image distance.
7 - FD The selected detector size.
8
Table lateral isocenter
oset
1
The lateral o
set of the table from the isocenter posion.
9
Table longitudinal iso-
center oset
1
The longitudinal o
set of the table from the isocenter posion.
10
Table height isocenter
oset
1
The height o
set of the table from the isocenter posion.
11
Isocenter
1
The table is in the isocenter posion.
Quick Reference Status Area
