16-bit general purpose timers (TIM2, TIM3, TIM5) RM0016

228/449 Doc ID 14587 Rev 8

18.6.6 Status register 2 (TIMx_SR2)

Address offset: 0x03 or 0x05 (TIM2), 0x03 (TIM3), 0x05 (TIM5); for TIM2 address see

Section

Reset value: 0x00

76543210

Reserved

CC3OF CC2OF CC1OF

Reserved

rc_w0 rc_w0 rc_w0

Bits 7:4 Reserved

Bit 3 CC3OF: Capture/compare 3 overcapture flag

Refer to CC1OF description

Bit 2 CC2OF: Capture/compare 2 overcapture flag

Refer to CC1OF description

Bit 1 CC1OF: Capture/compare 1 overcapture flag

This flag is set by hardware only when the corresponding channel is configured in input capture

mode. It is cleared by software by writing it to 0.

0: No overcapture has been detected

1: The counter value has been captured in TIMx_CCR1 register while CC1IF flag was already set

Bit 0 Reserved, forced by hardware to 0
