Analog/digital converter (ADC) RM0016
434/449 Doc ID 14587 Rev 8
24.11.13 ADC low threshold register high (ADC_LTRH)
Address offset: 0x2A
Reset value: 0x00
Note: This register is not available for ADC2.
24.11.14 ADC low threshold register low (ADC_LTRL)
Address offset: 0x2B
Reset value: 0x00
Note: This register is not available for ADC2.
76543210
LT[9:2]
rw rw rw rw rw rw rw rw
Bits 7:0 LT[9:2] Analog watchdog low voltage threshold MSB
These bits are set and cleared by software. They define the MSB of the low
Threshold (V
REFL
) for the Analog Watchdog.
76543210
Reserved
LT[1:0]
rw rw
Bits 7:2 Reserved, must be kept cleared.
Bits 1:0 LT[1:0] Analog watchdog low voltage threshold LSB
These bits are set and cleared by software. They define the LSB of the low
threshold (V
REFL
) for the Analog Watchdog.
