Analog/digital converter (ADC) RM0016

430/449 Doc ID 14587 Rev 8

24.11.6 ADC configuration register 3 (ADC_CR3)

Address offset: 0x23

Reset value: 0x00

Note: This register is not available for ADC2.

76543210

DBUF OVR

Reserved

rw rc_w0

Bit 7 DBUF: Data buffer enable

This bit is set and cleared by software. It is used together with the CONT bit

enable buffered continuous mode (DBUF=1, CONT=1). When DBUF is set,

converted values are stored in the ADC_DBxRH and ADC_DBxRL registers

instead of the ADC_DRH and ADC_DRL registers.

0: Data buffer disabled

1: Data buffer enabled

Bit 6 OVR: Overrun flag

This bit is set by hardware and cleared by software.

0: No overrun

1: An overrun was detected in the data buffer registers.

Refer to Section 24.5.5 on page 416 for more details.

Bits 5:0 Reserved, must be kept cleared.
