ST STM8S Reference Manual

RM0016 Analog/digital converter (ADC)
Doc ID 14587 Rev 8 433/449
24.11.11 ADC high threshold register high (ADC_HTRH)
Address offset: 0x28
Reset value: 0xFF
Note: This register is not available for ADC2.
24.11.12 ADC high threshold register low (ADC_HTRL)
Address offset: 0x29
Reset value: 0x03
Note: This register is not available for ADC2.
76543210
HT[9:2]
rw rw rw rw rw rw rw rw
Bits 7:0 HT[9:2] Analog Watchdog High Voltage threshold MSB
These bits are set and cleared by software. They define the MSB of the high
threshold (V
REFH
) for the Analog Watchdog.
76543210
Reserved
HT[1:0]
rw rw
Bits 7:2 Reserved, must be kept cleared.
Bits 1:0 HT[1:0] Analog watchdog high voltage threshold LSB
These bits are set and cleared by software. They define the LSB of the high
threshold (V
REFH
) for the Analog Watchdog.
