Universal asynchronous receiver transmitter (UART) RM0016

358/449 Doc ID 14587 Rev 8

22.7.11 Guard time register (UART_GTR)

Address offset: 0x09 (UART1), 0x0A (UART2)

Reset value: 0x00

76543210

GT[7:0]

rw rw rw rw rw rw rw rw

Bits 7:0 GT[7:0]: Guard time value.

This register gives the Guard time value in terms of number of baud clocks.

This is used in Smartcard mode.The Transmission Complete flag is set after this guard time value.

Note: These bits are not available for UART3.
