RM0016 Clock control (CLK)

Doc ID 14587 Rev 8 95/449

9.9.8 Peripheral clock gating register 2 (CLK_PCKENR2)

Address offset: 0x0A

Reset value: 0xFF

76543210

PCKEN2[7:0]

rw rw rw rw rw rw rw rw

Bits 7:0 PCKEN2[7:0]: Peripheral clock enable

These bits are written by software to enable or disable the f

MASTER

clock to the corresponding

peripheral. See Ta bl e 17

0: f

MASTER

to peripheral disabled

1: f

MASTER

to peripheral enabled

Table 18. Peripheral clock gating bits

Control bit Peripheral

PCKEN27 CAN (product dependent, see datasheet)

PCKEN26 Reserved

PCKEN25 Reserved

PCKEN24 Reserved

PCKEN23 ADC

PCKEN22 AWU

PCKEN21 Reserved

PCKEN20 Reserved
