RM0016 Interrupt controller (ITC)
Doc ID 14587 Rev 8 67/449
6.9 ITC and EXTI registers
6.9.1 CPU condition code register interrupt bits (CCR)
Address: refer to the general hardware register map table in the datasheet.
Reset value: 0x28
76543210
V–I1HI0NZC
rrrwrrwrrr
Bits 5, 3
(1)
I[1:0]: Software interrupt priority bits
(2)
These two bits indicate the software priority of the current interrupt request. When an
interrupt request occurs, the software priority of the corresponding vector is loaded
automatically from the software priority registers (ITC_SPRx).
The I[1:0] bits can be also set/cleared by software using the RIM, SIM, HALT, WFI, IRET or
PUSH/POP instructions (see Figure 16: Nested interrupt management).
I1 I0 Priority Level
1 0 Level 0 (main)
Low
High
01Level 1
00Level 2
1 1 Level 3 (= software priority disabled*)
1. Refer to the central processing section for details on the other CCR bits.
2. TLI, TRAP and RESET events can interrupt a level-3 program.
