16-bit advanced control timer (TIM1) RM0016

204/449 Doc ID 14587 Rev 8

17.7.14 Capture/compare enable register 2 (TIM1_CCER2)

Address offset: 0x0D

Reset value: 0x00

17.7.15 Counter high (TIM1_CNTRH)

Address offset: 0x0E

Reset value: 0x00

76543210

Reserved

CC4P CC4E CC3NP CC3NE CC3P CC3E

rw rw rw rw rw rw

Bits 7:6 Reserved

Bit 5 CC4P: Capture/compare 4 output polarity

Refer to CC1P description.

Bit 4 CC4E: Capture/compare 4 output enable

Refer to CC1E description.

Bit 3 CC3NP: Capture/compare 3 complementary output polarity

Refer to CC1NP description.

Bit 2 CC3NE: Capture/compare 3 complementary output enable

Refer to CC1NE description.

Bit 1 CC3P: Capture/compare 3 output polarity

Refer to CC1P description.

Bit 0 CC3E: Capture/compare 3 output enable

Refer to CC1E description.

76543210

CNT[15:8]

rw rw rw rw rw rw rw rw

Bits 7:0 CNT[15:8]: Counter value (MSB)
