Controller area network (beCAN) RM0016

378/449 Doc ID 14587 Rev 8

23.6.4 Message storage

The interface between the software and the hardware for the CAN messages is

implemented by means of mailboxes. A mailbox contains all information related to a

message; identifier, data, control, status and time stamp information.

Transmit mailbox

The software sets up the message to be transmitted in an empty transmit mailbox. The

status of the transmission is indicated by hardware in the CAN_MCSR register.

Table 65. Transmit mailbox mapping

Offset to Transmit Mailbox base

address (bytes)

0CAN_MCSR

1 CAN_MDLCR

2 CAN_MIDR1

3 CAN_MIDR2

4 CAN_MIDR3

5 CAN_MIDR4

6CAN_MDAR1

7CAN_MDAR2

8CAN_MDAR3

9CAN_MDAR4

10 CAN_MDAR5

11 CAN_MDAR6

12 CAN_MDAR7

13 CAN_MDAR8

14 CAN_MTSRL

15 CAN_MTSRH
