2000/3000 SHEET FINISHERS (B700/B701) August, 2006
1-68
2. Attach the rear joint bracket [A] ( x 2, M4 x 14).
3. Attach the front joint bracket [B] ( x 2, M4 x 14).
B700I105.WMF
[A]
[B]
