August, 2006
COPIER E-STUDIO4500C/5500C
1-13
Installation
8.
Remove th
e tag
, and r
od [A] (
x
1).
9.
Disconnect th
e fan con
nector [B].
10.
Remov
e the face
plate [C] (
x 5).
11.
Put the
PCU stand [D
] on a
flat, clea
n surfac
e.
12.
Use a cle
an cloth t
o remov
e dust
from the s
urface
of the stan
d.
B132I715.
W
MF
B132I902.
W
M
FF
[D]
[A]
[B]
[C]
51
53
