Toshiba e-STUDIO4500c Service Manual

SERVICE PROGRAM TABLES April, 2007
5-28
1108
Htg Roll Lamp 1 Heating Roller: Fusing Lamps
Controls the level of the power (percentage) supplied to the heating rollers (Watts)
when the machine is in the specified mode.
At Reload During warmup after the machine is switched or returns from
and energy save mode.
Wait Time While the machine is in the standby mode and ready for
operation.
Norm:1C Normal operation for black-and-white copying and printing.
Norm:FC Normal operation for full color copying and printing
Scan:Norm:1C Black-and-white scanning.
Scan:Norm:FC Full color scanning.
At ProCon Reload Reload temperature after completing the process control
cycle.
Heating Roller: Fusing Lamp 1
001
At Reload [ 0~100 / 100 /0.1%]
002
Wait Time
003
Norm:1C
004
Norm:FC
Heating Roller: Fusing Lamp 2
005
Wait Time [ 0~1000 /0.1%]
006
Norm:1C [ 0~1000 / 1000 /0.1%]
007
Scan:Norm:1C [ 0~100 /0.1%]
008
Norm:FC
009
Scan:Norm:FC [ 0~1000 /0.1%]
Pressure Roller Fusing Lamp
010
At Reload [ 0~100 / 100 /0.1%]
011
At ProCon Reload [ 0~100 /0.1%]
012
Wait Time [ 0~100 / 100 /0.1%]
013
Norm:1C
014
Norm:FC
Hot Roller Fusing Lamp
015
At Reload [ 0~100 / 100 /0.1%]
016
Wait Time
Heating Roller: Fusing Lamp 2
017
At Reload [ 0~100 / 100 /0.1%]
