COPIER INPUT/OUTPUT CHECK August, 2006
5-192
003 Paper Feed 3
Bit Input 0 1
Bit 7 Paper Size – Tray 3
Bit 6 Paper Size – Tray 3
Bit 5 Paper Size – Tray 3
Bit 4 Paper Size – Tray 3
Bit 3 Paper Size – Tray 3
See following
table.
Bit 2
Bit 1
Bit 0
Paper Size Table: 002, 003
Size Bit 7
Bit 6
Bit 5 Bit 4
Bit 3
12"x18" 1 1 1 1 1
A3 1 1 0 0 1
B4 1 0 0 1 1
A4 SEF 0 1 0 0 1
A4 LEF 1 1 0 0 0
B5 SEF 1 0 1 0 1
B5 LEF 0 0 0 1 1
A5 SEF 1 1 1 0 1
A5 LEF 0 1 1 0 1
DLT (11"x17") 1 1 1 0 0
LG (8½x14") 1 0 1 1 0
LT SEF (8½x11") 1 1 0 1 0
LT LEF 0 1 1 0 0
HLT SEF 0 1 1 1 0
HLT LEF 1 1 1 1 0
F4 (8 ½" x 13") 1 1 0 1 1
Folio (8¼ x 13") 0 1 0 1 1
F (8" x 13") 0 1 1 1 1
Executive SEF (7¼"x10½")
1 0 1 0 0
Executive LEF 0 0 1 1 1
8K SEF 0 0 1 1 0
16 SEF 1 0 0 1 0
16 LEF 1 0 1 1 1
004 Paper Feed 4
Bit Input 0 1
Bit 7
Bit 6
Bit 5 Paper Height Sensor – Tray 2
Bit 4 Paper Height Sensor – Tray 3
See following
table.
Bit 3
Bit 2
Bit 1 Paper Near End Sensor – Tray 2
Bit 0 Paper Near End Sensor – Tray 3
See following
table.
Paper Height, Near End: 004
100%
50%
30%
10%
Paper Height
0 1 1 0
Near End 0 0
1 1
