August, 2006 COPIER INPUT/OUTPUT CHECK
5-193
005: Paper Feed 5
Bit Input 0 1
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2 Right Tray Paper Sensor – Tray 1 No Paper Paper
Bit 1 Number of Trays Detected 3-Trays 4-Trays
Bit 0
006: Paper Feed 6
Bit Input 0 1
Bit 7 Tray 1 Set Sensor Off On
Bit 6 Rear Fence HP Sensor – Right Off On
Bit 5 Right Tray Down Sensor Off On
Bit 4 Rear Fence HP Sensor – Tray 1 Off On
Bit 3 Rear Fence Open Senor – Right Off On
Bit 2 Rear Fence Return Sensor – Tray 1 Off On
Bit 1 Paper End Sensor – Right Tray Off On
Bit 0 Right Tray Set Sensor – Tray 1 Off On
007: Paper Feed 7
Bit Input 0 1
Bit 7 Paper Feed Sensor – Tray 1 On Off
Bit 6
Bit 5 Paper Feed Sensor – Tray 2 On Off
Bit 4 Paper Feed Sensor – Tray 3 On Off
Bit 3 Vertical Transport Sensor – Tray 1 On Off
Bit 2
Bit 1 Vertical Transport Sensor – Tray 2 On Off
Bit 0 Vertical Transport Sensor – Tray 3 On Off
On = Paper present
Off = No paper
008: Paper Feed 8
Bit Input 0 1
Bit 7 Lift Sensor – Tray 1 On Off
Bit 6
Bit 5 Lift Sensor – Tray 2 On Off
Bit 4 Lift Sensor – Tray 3 On Off
Bit 3 Paper End Sensor – Tray 1 On Off
Bit 2
Bit 1 Paper End Sensor – Tray 2 On Off
Bit 0 Paper End Sensor – Tray 3 On Off
On: Tray up, No paper
Off: Tray down, paper present
