Toshiba e-STUDIO4500c Service Manual

COPIER INPUT/OUTPUT CHECK August, 2006
5-194
009: Used Toner Trans
Bit Input 0 1
Bit 7
Bit 6 WasteToner Lock Sensor Off On
Bit 5 Waste Toner Bottle Full Sensor Off On
Bit 4 Waste Toner Bottle Set Sensor Off On
Bit 3 Waste Toner Bottle Near Full Sensor Off On
Bit 2
Bit 1
Bit 0
010: Paper Trans 1
Bit Input 0 1
Bit 7 Duplex Transport Sensor 1 Off On
Bit 6 Duplex Transport Sensor 2 Off On
Bit 5 Duplex Transport Sensor 3 Off On
Bit 4 Duplex Inverter Sensor Off On
Bit 3 Duplex Entrance Sensor Off On
Bit 2
Bit 1
Bit 0
011: Paper Trans 2
Bit Input 0 1
Bit 7 LCT Relay Sensor Off On
Bit 6 Paper Exit Relay Sensor Off On
Bit 5 Registration Sensor Off On
Bit 4 Guide Plate Position Sensor Off On
Bit 3
Bit 2 Paper Exit Sensor Off On
Bit 1 Paper Exit Relay Sensor Off On
Bit 0 Off On
012: Paper Trans 3
Bit Input 0 1
Bit 7 Copy Tray Full Sensor Off On
Bit 6 Double-Feed Detection Sensor Off On
Bit 5 Accordion Jam Sensor Off On
Bit 4 Fusing Exit Sensor Off On
Bit 3
Bit 2
Bit 1
Bit 0
