August, 2006 COPIER INPUT/OUTPUT CHECK
5-195
013: Paper Trans 4
Bit Input 0 1
Bit 7 Paper Size Switch 1
Bit 6 Paper Size Switch 2
Bit 5 Paper Size Switch 3
Bit 4 Paper Size Switch 4
See
following
table.
Bit 3 Bypass Paper Size Switch Off On
Bit 2
Bit 1
Bit 0
Bypass paper end sensor: Off: Paper present, On: No paper
Paper Size Table: 013 (Trays 1 to 3, Bit 7 to 4)
Tray Sensor SW
NA EU/Asia
1 2 3 4 5
Postcard (100 x 148 mm) Postcard (100 x 148 mm) L H H H H
5 ½ x 8 ½ SEF A5 SEF L H H H L
5 ½ x 8 ½ SEF A5 SEF L H H H L
8 ½ x 14 SEF 8 x 13 SEF L H H L H
8 ½ x 14 SEF A4 SEF L H L L H
8 ½ x 14 SEF A3 SEF L H L L H
11 x 17 SEF A3 SEF L L L H H
A3 SEF A3 SEF L L H H H
Paper Size Table: 013 (Bypass Tray Bit 3)
Tray Sensor SW
NA EU/Asia
1 2 3 4 5
Postcard (100 x 148 mm) Postcard (100 x 148 mm) L H H H H
5 ½ x 8 ½ SEF A5 SEF L H H H L
5 ½ x 8 ½ SEF A5 SEF L H H H L
8 ½ x 14 SEF 8 x 13 SEF L H H L H
8 ½ x 14 SEF A5 LEF L H L L H
8 ½ x 14 SEF A4 LEF L H L L H
11 x 8 ½ SEF A4 LEF L L L H H
A4 LEF A4 LEF L L H H H
014: Drum Mtr Lock
Bit Input 0 1
Bit 7 Drum Motor Lock – Y Off On
Bit 6 Drum Motor Lock – M Off On
Bit 5 Drum Motor Lock – C Off On
Bit 4 Drum Motor Lock – K Off On
Bit 3
Bit 2
Bit 1
Bit 0
Off: No Lock
On: Locked
