Toshiba e-STUDIO4500c Service Manual

August, 2006 COPIER INPUT/OUTPUT CHECK
5-197
019: Fan System 3
Bit Input 0 1
Bit 7 Controlling Box Cooling Fan Motor 2 Lock Off On
Bit 6 Controlling Box Cooling Fan Motor 1 Lock Off On
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
Off: No Lock
On: Locked
020: Hi Volt SC1 (Drum Charge Power Pack)
Bit Input 0 1
Bit 7 High Voltage Output: Y Normal
Abnormal
Bit 6 High Voltage Output: M Normal
Abnormal
Bit 5 High Voltage Output: C Normal
Abnormal
Bit 4 High Voltage Output: K Normal
Abnormal
Bit 3
Bit 2
Bit 1
Bit 0
021: Hi Volt SC2 (Development Bias Power Pack)
Bit Input 0 1
Bit 7 High Voltage Output: Y Normal
Abnormal
Bit 6 High Voltage Output: M Normal
Abnormal
Bit 5 High Voltage Output: C Normal
Abnormal
Bit 4 High Voltage Output: K Normal
Abnormal
Bit 3
Bit 2
Bit 1
Bit 0
022: Hi Volt SC3 (Transfer Power Pack, Separation Power Pack)
Bit Input 0 1
Bit 7 High Voltage Output: Y Normal
Abnormal
Bit 6 High Voltage Output: M Normal
Abnormal
Bit 5 High Voltage Output: C Normal
Abnormal
Bit 4 High Voltage Output: K Normal
Abnormal
Bit 3 High Voltage Output: Y
Transfer PP
Normal
Abnormal
Bit 2 Paper Separation Separation PP
Normal
Abnormal
Bit 1
Bit 0
