Toshiba e-STUDIO4500c Service Manual

COPIER INPUT/OUTPUT CHECK August, 2006
5-198
023: Paper Transfer
Bit Input 0 1
Bit 7 ITB Lift Sensor Separated
Contact
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1 ITB Position Sensor 1
Bit 0 ITB Position Sensor 2
See folloeing table.
Bit Table: 023
Bit 1/Bit 0 Function
00 Belt Scale Control
01 Encoder Control
10 Belt or Sensor Defective
11 Belt or Sensor Defective
024: Toner Supply
Bit Input 0 1
Bit 7 Toner End Sensor: Y Off On
Bit 6 Toner End Sensor: M Off On
Bit 5 Toner End Sensor: C Off On
Bit 4 Toner End Sensor: K Off On
Bit 3
Bit 2
Bit 1
Bit 0
Off: Toner
On: Toner End
025: Fusing Temp Detect
Bit Input 0 1
Bit 7 Pressure Roller Thermostat – High Temp Off On
Bit 6 Hot Roller Thermistor – High Temp Off On
Bit 5 Heating Roller Temperataure Sensor – High Temp Off On
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
Off: Temperature within normal range
On: Temperature high, exceeded normal range
