Toshiba e-STUDIO4500c Service Manual

August, 2006 COPIER INPUT/OUTPUT CHECK
5-199
026: Set Detection
Bit Input 0 1
Bit 7 Key Card Set Off On
Bit 6 Key Count Set Off On
Bit 5 Mechanical Counter B Set Off On
Bit 4 Mechanical Counter FC Set Off On
Bit 3 Fusing Unit Set Off On
Bit 2 Duplex Unit Set Off On
Bit 1 Drawer Set Off On
Bit 0
027: Door
Bit Input 0 1
Bit 7 Front Door Switches Off On
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
028: Peltier Unit
Bit Input 0 1
Bit 7 Peltier Unit Abnormal Off On
Bit 6 Peltier Unit Fan Motor Off On
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
201: DIP Switches
Bit Input 0 1
Bit 7 DIP-SW7 Off On
Bit 6 DIP-SW6 Off On
Bit 5 DIP-SW5 Off On
Bit 4 DIP-SW4 Off On
Bit 3 DIP-SW3 Off On
Bit 2 DIP-SW2 Off On
Bit 1 DIP-SW1 Off On
Bit 0 DIP-SW0 Off On
