Copper Mountain Technologies S2 Series User Manual

S2VNA and S4VNA SCPI Programming Manual
105
CALC:LIM:DATA
CALCulate <Ch> [:SELected]:LIMit:DATA <numeric list>
CALCulate <Ch> [:SELected]:LIMit:DATA?
Description
Sets the data array, which is the limit line in the limit test function.
The array size is 1 + 5N, where N is the number of limit line
segments.
For the n–th point, where n from 1 to N:
<numeric 1> the number of limit line segments N is from 0 to
100. Setting 0 clears the limit line.
<numeric 5n–3> type of the n–th limit line segment
0: Off.
1: Upper limit
2: Lower limit
3: Single Point limit
<numeric 5n–2> the stimulus value in the start point of the n–th
segment
<numeric 5n–1> the stimulus value in the end point of the n–th
segment
<numeric 5n–0> the response value in the start point of the n–th
segment
<numeric 5n+1> the response value in the end point of the n–th
segment
(command/query)
Target
The active trace of channel <Ch>,
<Ch>={[1]|2|...16}
Query Response
<numeric 1>, <numeric 2>, …<numeric 5N+1>
Notes
If the array size is not 1 + 5N, where N is <numeric 1>, an error occurs. If
<numeric 5n–3> is less than 0 or more than 2, an error occurs. When
<numeric 5n–2>, <numeric 5n–1>, <numeric 5n–0>, and <numeric 5n+1>
elements are out of allowable range, the value is set to the limit, which is
closer to the specified value.
Equivalent Softkeys
Analysis > Limit Test > Edit Limit Line
