Copper Mountain Technologies S2 Series User Manual

S2VNA and S4VNA SCPI Programming Manual
144
CALC:RLIM:DATA
CALCulate <Ch> [:SELected]:RLIMit:DATA <numeric list>
CALCulate <Ch> [:SELected]:RLIMit:DATA?
Description
Sets the data array, which is the limit line for the ripple limit
function.
The array size is 1 + 4N, where N is the number of limit line
segments.
For the n–th point, where n from 1 to N:
<numeric 1> the number of limit line segments N is the
integer from 0 to 12. Setting 0 clears the limit
line.
<numeric 4n–2> type of the n–th limit line segment
0: Off.
1: On
<numeric 4n–1> the stimulus value in the beginning point of the
n–th segment
<numeric 4n–0> the stimulus value in the end point of the n–th
segment
<numeric 4n+1> the ripple limit value of the n–th segment
(command/query)
Target
The active trace of channel <Ch>,
<Ch>={[1]|2|...16}
Query Response
<numeric 1>, <numeric 2>, …<numeric 4N+1>
Notes
If the array size is not 1 + 4N, where N is <numeric 1>, an error occurs.
If <numeric 4n–2> is less than 0 or more than 1, an error occurs. When
<numeric 4n–1>, <numeric 4n–0>, and <numeric 4n+1> elements
are out of allowable range, the value is set to the limit, which is closer to
the specified value.
Equivalent Softkeys
Analysis > Ripple Limit > Edit Ripple Limit
