S2VNA and S4VNA SCPI Programming Manual
51
CALC:FSIM:BAL:DZC:BPOR:Z0
CALCulate<
Ch
>:FSIMulator:BALun:DZConversion:BPORt<
Bpt
>:Z0[:R]
<numeric>
CALCulate<
Ch
>:FSIMulator:BALun:DZConversion:BPORt<
Bpt
>:Z0[:R]?
Description
Sets or reads out the impedance value for the differential
impedance conversion function of the balanced port. The
impedance is real. The default impedance value equals to 100 Ω.
(command/query)
Target
Balanced Port <Bpt> of channel <Ch>,
<Ch>={[1]|2|...16}
<Bpt>={[1]|2}, 1 or 2 for the Bal-Bal topology, always 1 for the SE-Bal,
SE-SE-Bal and Bal topology.
Parameter
<numeric> the new value of the differential impedance of the balanced
port from 1 mΩ to 10 MΩ.
Unit
Ω (Ohm)
Out of Range
Sets the value of the limit, which is closer to the specified value.
Query Response
<numeric>
Preset Value
100 Ω
Equivalent Softkeys
Analysis > Fixture Simulator > Diff ZConversion > Bal Port n
