Copper Mountain Technologies S2 Series User Manual

S2VNA and S4VNA SCPI Programming Manual
229
SENS:CORR:COLL:CKIT:STAN:ARB
SENSe:CORRection:COLLect:CKIT:STAN <Std> :ARBitrary <numeric>
SENSe:CORRection:COLLect:CKIT:STAN <Std> :ARBitrary?
Description
Sets or reads out the value of the arbitrary impedance for the load
standard.
(command/query)
Target
Standard <Std> of the selected calibration kit,
<Std>={[1]|2|...N}, where N – the number of the standards in
the calibration kit
Parameter
<numeric> the arbitrary impedance value from –1E18 to 1E18
Unit
Ω (Ohm)
Out of Range
Sets the value of the limit, which is closer to the specified value.
Query Response
<numeric>
Preset Value
50 or 75, depending on the selected calibration kit
Equivalent Softkeys
Calibration > Cal Kit > Define STDs > Terminal Impedance
