S2VNA and S4VNA SCPI Programming Manual
106
CALC:LIM:DISP
CALCulate <Ch> [:SELected]:LIMit:DISPlay[:STATe] {OFF|ON|0|1}
CALCulate <Ch> [:SELected]:LIMit:DISPlay[:STATe]?
Description
Turns ON/OFF the limit line display of the limit test function.
(command/query)
Target
The active trace of channel <Ch>,
<Ch>={[1]|2|...16}
Parameter
{ON|1} : ON
{OFF|0} : OFF
Query Response
{0|1}
Preset Value
0
Equivalent Softkeys
Analysis > Limit Test > Limit Line
CALC:LIM:FAIL?
CALCulate <Ch> [:SELected]:LIMit:FAIL?
Description
Reads out the limit test result.
(query only)
Target
The active trace of channel <Ch>,
<Ch>={[1]|2|...16}
Query Response
1 : Fail
0 : Pass
Equivalent Softkeys
None
