S2VNA and S4VNA SCPI Programming Manual
175
DISP:WIND:TRAC:ANN:MARK:POS:Y
DISPlay:WINDow <Ch> :TRACe <Tr> :ANNotation:MARKer:POSition:Y <numeric>
DISPlay:WINDow <Ch> :TRACe <Tr> :ANNotation:MARKer:POSition:Y?
Description
Sets or reads out the display position of the marker annotation on
the Y–axis by a percentage of the display height.
(command/query)
Target
Trace <Tr> of channel <Ch>,
<Tr>={[1]|2|...16}
<Ch>={[1]|2|...16}
Parameter
<numeric> the display position of the marker value on the Y–axis from
0 to 100
Unit
% (percent)
Out of Range
Sets the value of the limit, which is closer to the specified value.
Query Response
<numeric>
Preset Value
0
Equivalent Softkeys
Markers > Properties > Data Y Position
